Radium Fuel Rail, Top Feed Conversion, Mazda 13B Primary

Item: Radium Fuel Rail, Top Feed Conversion, Mazda 13B Primary

PORTS AND FITTINGS

The fuel rail ports are tapped for 8AN ORB.

8AN ORB Adapter Fittings can be found  .
8AN ORB Direct Mount Regulators can be found  .
8AN ORB Fuel Pulse Dampers can be found  .
Fuel Pressure Gauge Adapters can be found  .

Appropriate fittings must be selected based on the specific application. Ample space around the fuel rail port(s) is necessary for larger accessories such as fuel pressure regulators, fuel pressure gauges, and fuel pulse dampers. To verify clearance, the dimensional drawings on the product pages can be used as a reference guide.

The Radium Engineering high flow primary fuel rail is for the 13B-RE and 13B-REW rotary engine found in the 1990-1995 Mazda/Eunos Cosmo and 1992-2002 Mazda RX7 FD3S. The aluminum fuel rail is anodized black for compatibility with all popular fuel types including E85. Manufactured with a large internal bore, the fuel rail can support all necessary engine power requirements.

The three 8AN ORB ports are compatible with these fittings  . The extra center port allows additional fuel system accessories such as the OEM fuel temperature sensor (using  ), a pressure transducer,   (shown below) etc.

Insulating phenolic spacers and washers are included with stainless steel hardware to prevent thermal energy from conducting heat into the fuel.

The included 14mm lower injector seats (shown above) were designed specifically to be compatible with or without the OEM diffusers in place. They feature Viton O-rings making them suitable for boosted applications.
