TOMEI OIL PAN BAFFLE PLATE RB26DETT
TOMEI OIL PAN BAFFLE PLATE RB26DETT
SKU: 193034

TOMEI OIL PAN BAFFLE PLATE RB26DETT

$334.24

or 4 payments of $83.56 with Info



In Stock


Calculate Shipping


Australia wide rate - $20.00 (ETA: 3 days)


OIL PAN BAFFLE PLATE
When the vehicle is on the corner or the time of acceleration and deceleration, oil in the oil pan will lean or jump. To prevent these to happen, baffle is assembled in the pan of stock engine. Though, in terms of sports driving, it is almost impossible to achieve its purpose because the size of the baffle is restricted to cut down the production cost. If oil leans to one side largely, air goes in to the pipe instead of oil and interrupts continuous oil lubrication. Without oil, metal surface contact directly each other, then the temperature rises explosively and causing worn out if its lasts long. On the other hand, Tomei movable baffle plate is made to achieve stable oil lubrication at any situations such as curving, acceleration, and deceleration. And it will secure the improvement of engine performance from street use to the drag racing or circuit run.

lower part
lower assembled
upper assembled
Newly developed rubber valve

Product
Model
Engine code
Part number

Note
Oil Pan Baffle Plate
BNR32
BCNR33
BNR34
RB26DETT
193034


SKU 193034
Brand TOMEI
Shipping Weight 1.5000kg
Shipping Width 0.320m
Shipping Height 0.100m
Shipping Length 0.280m
Shipping Cubic 0.008960000m3
