SKU: TOLEDO-227000
TOLEDO Twin Pull Puller Kit - Large 227000
PART NUMBER: 227000
Description
Twin Pull Mechanical Pullers
- Special pullers for the removal of blind housing bearings without the need to dismantle machinery or remove the running shaft
- Positive seating allows even tension on inner and outer bearing rings, reducing resistance
- Stabilisers reduce sideways movement and self centre the puller
- Three kits cover a wide range of ISO bearings. To identify kit for bearings without an ISO reference refer to puller spread and adaptor diameter
- Extensive range of spare parts available for all sets
- Special pullers for the removal of blind housing bearings without the need to dismantle machinery or remove the running shaft
- Positive seating allows even tension on inner and outer bearing rings, reducing resistance
- Stabilisers reduce sideways movement and self centre the puller
- Spread: 60-200mm
- Reach: 500mm
- Adaptor size: 16-32mm
- ISO bearing designation: 6021 - 6032 , 6309 - 6321 , 6212 - 6230 , 6406 - 6417
ITEM CONTENTS
Code | Name | Qty |
---|---|---|
227001 | Adaptor - 16mm | 1 |
227002 | Adaptor - 19mm | 1 |
227003 | Adaptor - 22mm | 1 |
227004 | Adaptor - 25mm | 1 |
227005 | Adaptor - 28mm | 1 |
227006 | Adaptor - 32mm | 1 |
227014 | Extension Rod - 250mm | 1 |
227011 | Forcing Screw - 270mm | 1 |
227013 | Main Rod - 250mm | 1 |
227016 | Sliding Twin Beam Internal - 240mm | 1 |
Specifications
SKU | TOLEDO-227000 |
Brand | TOLEDO |
Shipping Weight | 6.0000kg |
Shipping Width | 0.200m |
Shipping Height | 0.200m |
Shipping Length | 0.200m |
