Item: Raceworks Set of 4 980cc Full Length Fuel Injectors 14mm/Denso for Nissan Skyline R32, R33, R34INJ-505-RB26

Raceworks is a range of High Performance Air, Fuel, and Fluid Management Components.

Raceworks products are manufactured from premium quality materials to ensure the highest specifications and industry standards are surpassed.

Raceworks components include fuel pumps, silicone hoses, fuel rails, aluminium fittings, performance hose, fuel injectors, sensors, connectors and supporting hardware.

Raceworks is available through a network of specialised resellers and leading automotive retail groups who have a passion for performance.

Raceworks have developed a comprehensive range of performance fuel injectors, that now set the industry standard for quality and reliability, with a variety of flow rates, physical sizes and fuel compatibility ranging from pump fuel to E85 and Methanol. A full range of connector plug adaptors and extensions are also availalbe, enabling a quick and simple upgrade to almost any application. All Raceworks injectors are High Impedence with 14mm Viton O-Rings.

Features:

• Modified/High Flowed Bosch Injector
• Size: 980cc (95 Lb/hr) @ 3bar and 1150cc (110Lb/hr) @ 4bar.
• Impedance: High (12Ohms)
• Plug: USCAR.
• Top O-Ring: 14mm.
• Bottom O-Ring: Denso
• Ethanol & Methanol Safe
• Spray Pattern: Narrow Cone
• Spray Direction: Straight
• Supplied with Plugs and Pins, Wiring Required
• Sold flow matched to a +/- 1% Variance (2% Total)

Flywheel power figures per injector (Estimated):

Direct fit applications*:

• Nissan Skyline R32 RB20/RB25/RB26 (with 14mm Top Feed Fuel Rails, Denso Lower Seat)
• Nissan Skyline R33 RB20/RB25/RB26 (with 14mm Top Feed Fuel Rails, Denso Lower Seat)
• Nissan Skyline R34 RB20/RB25/RB26 (with 14mm Top Feed Fuel Rails, Denso Lower Seat)

*Injectors are a direct fit physically, but as with all Raceworks Injectors, will require a tune. While the vehicles listed above are direct fit, the injector can be used in many other applications with the appropriate extensions, o-rings or plug adapters.
