SKU: RWH-260-03-3M

Raceworks 260 Series Braided Teflon E85 Hose w/Black PVC Coating 3 3 Metre RWH-260-03-3M

FITTING

$74.99

or 4 payments of $18.75 with Info



In Stock


Calculate Shipping



Australia wide rate - $25.00 (ETA: 3 days)

Description

Item: Raceworks 260 Series Braided Teflon E85 Hose w/Black PVC Coating 3RWH-260-03-3M

Raceworks is a range of High Performance AirFuel, and Fluid Management Components.

Raceworks products are manufactured from premium quality materials to ensure the highest specifications and industry standards are surpassed.

Raceworks components include fuel pumps, silicone hoses, fuel rails, aluminium fittings, performance hose, fuel injectors, sensors, connectors and supporting hardware.

Raceworks is available through a network of specialised resellers and leading automotive retail groups who have a passion for performance.

Raceworks 260 Series Teflon Braided Hose is constructed from a PTFE (Teflon) inner tube that is compatible with all fuels, oils, nitrous including brake and clutch fluids. The PTFE (Teflon) tube is covered by a stainless steel outer cover that is then covered with a Black PVC cover for extra durability, and resistance to abrasion and expansion. The Raceworks 260 Series Hose is commonly used in braking and clutch systems. All Raceworks products come with a 2 year warranty.

Long lengths (greater than 10M) can be specially ordered. Please enquire with your Raceworks Dealer.

Temperature Range: -70°C to 250°C. Ethanol & Methanol Safe



Operating and Burst Pressure:

                         Operating Pressure    Burst Pressure
RWH-260-03 3000psi 10000psi



Specifications:

                                  Inside DIA. Inch Inside DIA. MM Outside DIA. Inch Outside DIA. MM Bend Radius Inch Bend Radius MM
RWH-260-03-1M 9/64" 3.6mm 9/32" 7.35mm 1" 26mm

Specifications

SKU RWH-260-03-3M
Brand RACEWORKS
Shipping Weight 5.0000kg
Shipping Width 0.360m
Shipping Height 0.200m
Shipping Length 0.300m
