Proflow Cylinder Heads Aluminium Holden Commodore VN Bare 590 HP Out of Box 63cc Chamber 200cc Intake Runner Pair
PROFLOW
Description
item: Proflow Cylinder Heads Aluminium Holden Commodore VN Bare 590 HP Out of Box 63cc Chamber 200cc Intake Runner Pair
Proflow Holden Commodore VN SuperMax Aluminium Heads Bare
Proflow does not sacrifice quality for a low price--you get both with our aluminium cylinder heads. The lightweight heads are cast from A-356 aluminium alloy with a large choice of Engine, for SB & BB Chevrolet, LS Chev Holden Ford SB 289-351W, 302,351 Cleveland 2V & 3V & BB FE, and Chrysler SB & BB, phosphorous bronze valve guides, and ductile iron valve seats for use with unleaded gas. They're also end-milled and drilled for accessories. The fully assembled heads have stainless steel valves, High Performance valve springs, 7 degree valve locks, rocker arm studs, and guideplates. Perfect for your Mild or High performance Hot Rod.
SPECIFICATIONS | |
Combustion Chamber | 63 cc |
Intake Port Volume | 200 cc |
Intake Port Dimensions | 2.170 (H) x 1.285 (W) |
Exhaust Port Volume | 72 cc |
Exhaust Port Dimensions | 1.450 (H) x 1.283 (W) |
Spark Plug Location | OEM |
Intake Valve Diameter | 2.020 |
Exhaust Valve Diameter | 1.60 |
Valve Stem Diameter | 8 mm |
Valve Spring Pocket ID | 1.650 |
Valve Guide OD | 0.530 |
Maximum Valve Lift | 0.700 |
Rocker Stud Thread Size | 7/16-14 |
Valve Angle | 5° |
Deck Thickness | 0.6875 |
Proflow Holden Commodore VN SuperMax Aluminium Heads Bare
Proflow does not sacrifice quality for a low price--you get both with our aluminium cylinder heads. The lightweight heads are cast from A-356 aluminium alloy with a large choice of Engine, for SB & BB Chevrolet, LS Chev Holden Ford SB 289-351W, 302,351 Cleveland 2V & 3V & BB FE, and Chrysler SB & BB, phosphorous bronze valve guides, and ductile iron valve seats for use with unleaded gas. They're also end-milled and drilled for accessories. The fully assembled heads have stainless steel valves, High Performance valve springs, 7 degree valve locks, rocker arm studs, and guideplates. Perfect for your Mild or High performance Hot Rod.
SPECIFICATIONS | |
Combustion Chamber | 63 cc |
Intake Port Volume | 200 cc |
Intake Port Dimensions | 2.170 (H) x 1.285 (W) |
Exhaust Port Volume | 72 cc |
Exhaust Port Dimensions | 1.450 (H) x 1.283 (W) |
Spark Plug Location | OEM |
Intake Valve Diameter | 2.020 |
Exhaust Valve Diameter | 1.60 |
Valve Stem Diameter | 8 mm |
Valve Spring Pocket ID | 1.650 |
Valve Guide OD | 0.530 |
Maximum Valve Lift | 0.700 |
Rocker Stud Thread Size | 7/16-14 |
Valve Angle | 5° |
Deck Thickness | 0.6875 |
Specifications
SKU | pf-PFEAHH20063-BARE |
Brand | PROFLOW |
Shipping Weight | 50.0000kg |
Shipping Width | 0.700m |
Shipping Height | 0.300m |
Shipping Length | 0.700m |
