Kelford Cams 254-A Camshaft for (Zetec) - 224/224 Deg
KELFORD CAMS
Description
item: Kelford Cams 254-A Camshaft for (Zetec) - 224/224 Deg
Description
The vision is for Kelford Cams to be known as one of the best in the camshaft industry, to be recognised worldwide for manufacturing high quality, high performance camshafts for the motorsport industry. We are a small company that, since 1968 has specialised in custom camshafts to suit the individual requirements of each racer. We have a vast knowledge of engine combinations for all types of motor sport and we know how to match camshafts to engine and vehicle requirements. All of our cams are manufactured in-house using ultra-modern design systems and ground using masterless CNC grinders with CBN cutting wheel technology for superior quality and consistency.
- 224/224 Degrees duration @ 1mm cam lift, 9.9mm/9.9mm lift
Specifications
 | |||||||
| Engine Make: | Engine Model: | Part Number: | |||||
| FORD | ZETEC | 254-A | |||||
| Valve Clearance: | Intake: | Set | at the | ||||
| Exhaust: | Set | at the | |||||
| Cam Lift: | Intake: | 9.90mm | Exhaust: | 9.90mm | |||
| Rocker Ratio: | Intake: | 1 | Exhaust: | 1 | |||
| Nett Valve Lift: | Intake: | 9.90mm | Exhaust: | 9.90mm | |||
| Advertised Duration @ | 0.10mm | Intake: | 262 | Exhaust: | 262 | ||
| Duration @ | 1mm VALVE LIFT | Intake: | 224 | Exhaust: | 224 | ||
| Timing @ | 1mm VALVE LIFT | IVO: | 6 BTDC | EVO: | 42 BBDC | ||
| IVC: | 38 ABDC | EVC: | 2 ATDC | ||||
| Suggested Centre Lines: | Intake: | 106 | Exhaust: | 110 | |||
| VALVE | Lift @ TDC | Intake: | 1.57mm | Exhaust: | 1.19 | ||
compatibility
- 1992-1998 Ford Mondeo 1.6 90 bhp (Engine codes: L1F, L1J)
- 1998-2001 Ford Mondeo 1.6 88 bhp (Engine codes: L1N, L1Q)
- 1992-1995 Ford Fiesta (1.6 90 bhp Si) (1.8 105 bhp S/XR2i 16V) (1.8 130 bhp RS1800)
- 1992-1998 Ford Escort (Europe) (1.6 90 bhp Si) (1.8 105/130 bhp XR3i) (1.8 115 bhp Si/GTi)
- 1999-2002 Mercury Cougar
- 2000-2003 Ford Escape and Mazda Tribute
- 2000-2003 Ford Focus
- 1998-2003 Ford Escort ZX2.
- 2003-On Formula Ford 2000 series
- 1998-2003 Ford Escort ZX2, 130 hp (97 kW) and 127 lb·ft (172 Nm)
- 1999-2000 Ford Escort ZX2 S/R, 143 hp (107 kW) and 146 lb·ft (198 Nm)
- 2000-2004 Ford Focus, 128 hp (97 kW) and 135 lb·ft (183 Nm)
- 2002-2004 Ford SVT Focus 170 hp (127 kW) and 145 lb·ft (197 Nm)
- 1995-2000 Ford Contour
- 1995-2000 Mercury Mystique
- 2001-2005 Ford Escape
- 2001-2005 Mazda Tribute
Specifications
| SKU | kelford-254-A |
| Brand | KELFORD CAMS |
| Shipping Weight | 25.0000kg |
| Shipping Width | 0.600m |
| Shipping Height | 0.200m |
| Shipping Length | 0.250m |
