Kelford Cams 239-B Camshaft Set for (2AZ-FE) - 272/266 Deg
Kelford Cams 239-B Camshaft Set for (2AZ-FE) - 272/266 Deg
SKU: kelford-239-B

Kelford Cams 239-B Camshaft Set for (2AZ-FE) - 272/266 Deg

KELFORD CAMS

$923.96

or 4 payments of $230.99 with Info



In Stock


Calculate Shipping


Australia wide rate - $45.00


item: Kelford Cams 239-B Camshaft Set for (2AZ-FE) - 272/266 Deg

Description

The vision is for Kelford Cams to be known as one of the best in the camshaft industry, to be recognised worldwide for manufacturing high quality, high performance camshafts for the motorsport industry. We are a small company that, since 1968 has specialised in custom camshafts to suit the individual requirements of each racer. We have a vast knowledge of engine combinations for all types of motor sport and we know how to match camshafts to engine and vehicle requirements. All of our cams are manufactured in-house using ultra-modern design systems and ground using masterless CNC grinders with CBN cutting wheel technology for superior quality and consistency.

  • 272/266 Degrees advertised duration. 9.35mm/8.75mm lift
  • 272 Degree high performance cams to suit mild race and rally car engines. Requires programmable ECU.

Specifications

Engine Make: Engine Model: Part Number:
TOYOTA 2AZ-FE 239-B
Valve Clearance: Intake: 0.20mm Set COLD at the CAM
  Exhaust: 0.25mm Set COLD at the CAM

Cam Lift:   Intake: 9.55mm Exhaust: 9.00mm
Rocker Ratio:   Intake: 1 Exhaust: 1
Nett Valve Lift:   Intake: 9.35mm Exhaust: 8.75mm
Advertised Duration @ 0.10mm Intake: 272 Exhaust: 266
Duration @ 1.00mm VALVE LIFT Intake: 230 Exhaust: 222
Timing @ 1.00mm VALVE LIFT IVO:   EVO: 41 BBDC
    IVC:   EVC: 1 ATDC
Suggested Centre Lines:   Intake: Vari Exhaust: 110
VALVE Lift @ TDC Intake:   Exhaust: 1.10




compatibility

  • 2002-2012 Toyota Camry
  • 2009-2011 Toyota Matrix S (USA)/XR (Canada)/XRS
  • 2009-2010 Pontiac Vibe
  • 2003-2012 Toyota RAV4
  • 2000-2007 Toyota Highlander/Kluger
  • 2000?2013 Toyota Harrier
  • 2000-2019 Toyota Estima / Toyota Previa / Toyota Tarago
  • 2001-2010 Toyota Ipsum
  • 2002?2015 Toyota Alphard
  • 2008?2015 Toyota Vellfire
  • 2006?2012 Toyota Blade
  • 2003-2010 Toyota Avensis
  • 2005-2010 Scion tC
  • 2008-2015 Scion xB
  • 2007-2013 Toyota MarkX Zio

SKU kelford-239-B
Brand KELFORD CAMS
Shipping Weight 25.0000kg
Shipping Width 0.600m
Shipping Height 0.200m
Shipping Length 0.250m
