Kelford Cams 239-A Camshaft Set for (2AZ-FE) - 264/260 Deg
KELFORD CAMS
Description
item: Kelford Cams 239-A Camshaft Set for (2AZ-FE) - 264/260 Deg
Description
The vision is for Kelford Cams to be known as one of the best in the camshaft industry, to be recognised worldwide for manufacturing high quality, high performance camshafts for the motorsport industry. We are a small company that, since 1968 has specialised in custom camshafts to suit the individual requirements of each racer. We have a vast knowledge of engine combinations for all types of motor sport and we know how to match camshafts to engine and vehicle requirements. All of our cams are manufactured in-house using ultra-modern design systems and ground using masterless CNC grinders with CBN cutting wheel technology for superior quality and consistency.
- 264/260 Degrees advertised duration. 9.35mm/8.75mm lift
- Mild street performance cam, noticeable idle
Specifications
Engine Make: | Engine Model: | Part Number: | |||||
TOYOTA | 2AZ-FE | 239-A | |||||
Valve Clearance: | Intake: | 0.20mm | Set | COLD | at the | CAM | |
Exhaust: | 0.25mm | Set | COLD | at the | CAM | ||
Cam Lift: | Intake: | 9.55mm | Exhaust: | 9.00mm | |||
Rocker Ratio: | Intake: | 1 | Exhaust: | 1 | |||
Nett Valve Lift: | Intake: | 9.35mm | Exhaust: | 8.75mm | |||
Advertised Duration @ | 0.10mm | Intake: | 264 | Exhaust: | 260 | ||
Duration @ | 1.00mm VALVE LIFT | Intake: | 218 | Exhaust: | 216 | ||
Timing @ | 1.00mm VALVE LIFT | IVO: | EVO: | 38 BBDC | |||
IVC: | EVC: | 2 BTDC | |||||
Suggested Centre Lines: | Intake: | Vari | Exhaust: | 110 | |||
VALVE | Lift @ TDC | Intake: | Exhaust: | 0.81 |
compatibility
- 2002-2012 Toyota Camry
- 2009-2011 Toyota Matrix S (USA)/XR (Canada)/XRS
- 2009-2010 Pontiac Vibe
- 2003-2012 Toyota RAV4
- 2000-2007 Toyota Highlander/Kluger
- 2000?2013 Toyota Harrier
- 2000-2019 Toyota Estima / Toyota Previa / Toyota Tarago
- 2001-2010 Toyota Ipsum
- 2002?2015 Toyota Alphard
- 2008?2015 Toyota Vellfire
- 2006?2012 Toyota Blade
- 2003-2010 Toyota Avensis
- 2005-2010 Scion tC
- 2008-2015 Scion xB
- 2007-2013 Toyota MarkX Zio
Specifications
SKU | kelford-239-A |
Brand | KELFORD CAMS |
Shipping Weight | 25.0000kg |
Shipping Width | 0.600m |
Shipping Height | 0.200m |
Shipping Length | 0.250m |
