Felpro Intake Gasket Set Suit SB Chev SB2 Mirror Port - Trim to fit

Item: Felpro Intake Gasket Set Suit SB Chev SB2 Mirror Port - Trim to fit

Fel-Pro ^® Performance MLS gaskets are composed of four to five stainless steel layers, along with proprietary coatings. Strategically-located sealing beads surround the combustion chamber and coolant passages, concentrating clamp load in the most critical areas.

Fel-Pro Performance Gaskets deliver reliable sealing under gruelling racing conditions

• Fel-Pro performance intake manifold gaskets have been tested with virtually all aftermarket cylinder head and intake manifold combinations.
• Performance intake manifold gaskets designed without a metal core, to allow engine builders to trim the gasket for exact fit on modified ports.
• No exhaust crossover openings or blocking shields
• For use with cast iron and aluminium cylinder heads
• Not intended for use in emission controlled vehicles.

Part Type Intake Manifold Gasket Set
Mfg. GM Performance
Engine Family Chevrolet V8 Racing Small Block
Engine Displacement SB2 (4.400 Bore Centres)

Specifications
Port Size (in.) 1.40 x 1.90
Port Shape Rectangle
Thickness (in.) 0.120
Materials/Construction Composite w/coating
Application Notes Aluminium heads w/non-conventional port and bolt locations -
Chevrolet SB2 Mirror Port - Trim to fit
Product Notes No exhaust crossover openings or blocking shields; Gaskets fit
many O.E. and aftermarket heads
