Item: Felpro 1208-3 Intake Gasket Set Suit LS Engine LS7

Fel-Pro ^® Performance MLS gaskets are composed of four to five stainless steel layers, along with proprietary coatings. Strategically-located sealing beads surround the combustion chamber and coolant passages, concentrating clamp load in the most critical areas.

Fel-Pro Performance Gaskets deliver reliable sealing under gruelling racing conditions

• Fel-Pro performance intake manifold gaskets have been tested with virtually all aftermarket cylinder head and intake manifold combinations.
• Performance intake manifold gaskets designed without a metal core, to allow engine builders to trim the gasket for exact fit on modified ports.
• Designed specifically for the LS7 platform
• Printoseal elastomeric sealing beads to provide extra sealing strength around the intake port.
• Not intended for use in emission controlled vehicles.

Part Type Intake Manifold Gasket Set
Mfg. GM Performance
Engine Family Chevrolet V8 LS Small Block
Engine Displacement

Specifications
(4.8L) 293, (5.3L) 325 (Truck Block Based), (5.7L) 346, (5.7L)
383 Stroker, (6.0L) 364, (6.0L) 369 Stroker, (6.0L) 402 Stroker,
(6.2L) 378, (7.0L) 427, Aftermarket Performance Block
Port Size (in.) 1.45 x 2.45
Port Shape Rectangle
Thickness (in.) 0.060
Materials/Construction Composite w/Printoseal®
Application Notes Rectangle Port
