Description

EWP & FAN DIGITAL CONTROLLER + Velcro (12 & 24V) (PART #8101)

**SUPERSEDED BY PART #8102**

*Please note: this part includes the controller and mounting Velcro for customer that may already have all other components due to replacing a damaged unit or upgrading from an older model.

For all other applications, please look at the full kit part number 8001.

For optimum control of Davies, Craig 12 Volt and 24 Volt Electric Water Pumps.
Suits EWP80, EWP115, EWP130, EWP150, Thermatic / Electric Fans and billeted style Electric Water Pumps.

The EWP/Fan Digital Controller has two specific functions.
This unique Digital Controller will manage the operation of the EWP by varying the speed of the pump in response to the coolant temperature and manage control of your electric engine fan.

The Controller has a push-button to lock in any temperature from 40°C (104°F) to 110°C (230°F). It’s recommended you set/target the Controller to closely match your engine’s existing thermostat temperature.
The Digital Controller will operate the engine’s electric fan automatically once the engine has reached +3°C (+5.4°F) above the targeted / set temperature. Another significant benefit is that the Controller allows the EWP & Fan to run on after ignition shutdown for either 3 minutes or -10°C (-14°F) of set set / target temperature to eliminate heat soak.

CONTENTS
ITEM	DESCRIPTION	UNITS
1	EWP Digital Controller	1
2	Velcro	2

EWP, Fan & LCD Controller Installation LCD Controller Wiring Instructions

Technical Specifications
Technical Specification - LCD Controller
Voltage range	12V DC to 29V DC
Display LCD size	70mm (2.76”) x 60mm (2.36”)
Maximum current	12Amps
Warning alarm	High & low Temp., Above set temp., Sensor short circuit, Pump error, High & low voltage and Sensor open circuit
Targeted (set) temperatures	Singular degrees from: 40°C (104°F) to 110°C (230°F)
Memory	Set & targeted temperature
Fan cut-in temp.	3°C (5.4°F) above the targeted (set) temperature
Controller type	PCB with micro-processor
Sensor type	Thermister in housing
Overrun/ shutdown	-10°C (14°F) below set/target temperature or 3 minutes
Indicators	Temperature, power, EWP, test, fan, high & low temp, voltage, above set temperature (with alarm)
Weight	100 grams (3.5 oz)
Dimensions	Length = 95mm (3.7") Width = 130mm (5.1") Depth = 25mm (1”)

This EWP / Fan Digital Controller (Part #8101) is Australian designed and as part of this Australian manufacturing company’s continuous improvement program this advanced Digital Controller boasts a suite of enhancements.

Features
Black & White Numerical Screen
Celsius or Fahrenheit display option
Warning Alarms:

- Plus 10°C (14°F) set/target temperature
- Under temp 40°C after 5 mins
- Temp sensor error
- Over or under voltage
- EWP error

Select any set temp range from 40°C (104°F) to 110°C (230°F)
Set / targeted temperature memory
Override feature to assist bleeding EWP & fail safe
Input voltage display
Compatible with billeted style Electric Water Pumps
