EBP15 - Electric Booster Pump Kit (Part #9001)
Superseded by Part #9050
| OBSOLETE PARTS | REPLACEMENT PARTS | ||
| Part # | Description | Part # | Description |
| 9001 | EBP15 - Electric Booster Pump Kit (12V) | 9050 | EBP23 - Electric Booster Pump Kit 12v |
| 9002 | EBP15 - Electric Booster Pump 12v & Wiring Loom | 9051 | EBP23 - Electric Booster Pump 12v (Pump Only) |
| SPECIFICATIONS |
| EBP15 | EB23 |
| Max Flowrate @ 0 Bar |
| 22.7 L/min | 23 L/min |
| Rated Flowrate @ 0.1 Bar |
| 15 L/min | 17.25 L/min |
| Max Head Height |
| 2.4m | 2.5m |
| Rated Voltage |
| 12V | 12V |
| Operating Voltage |
| 9-15V | 6-18V |
| Rated Life (continuous) |
| 15,000 hrs | 20,000 hrs |
A high-performance brushless motor, magnetic-drive pump. Compact and versatile 12V pump for a range of applications.
Davies, Craig developed the Electric Booster Pump (EBP15), designed for use with either an EWP or a conventional mechanical water pump to enhance the heater and LPG systems. This high-performance 15 litre per minute, 12 volt, brushless, magnetically-driven EBP has drawn high acclaim globally for its diversity of applications. These include booster for car heater
and LPG systems, solar and marine applications, water-cooled motorcycle, go-kart engines, turbo air/water intercoolers, caravans, motor homes and domestic irrigation.
The EBP is a recirculating pump which is ideal for a ‘closed system’ similar to an automotive cooling system; it is not self priming’.
For optimum coolant flow control, use either of the Davies, Craig Thermatic Switches (#0400, #0444 or #0455)
| Kit Contents | |
| Description | Qty |
| EBP15 Electric Booster Pump | 1 |
| Adaptor - stepped: 19mm (¾”), 15mm (9/16”), 12.5mm (½”) | 2 |
| Hose clamps | 4 |
| Hose | 2 |
| Wiring harness | 1 |
| Fitting instructions | 1 |
Technical Specifications
| Description | |
| Motor | 12 Volt Brushless |
| Operating voltage | 9V DC to 15V DC |
| Maximum current | 1.3A |
| Flow rate (max) | 15 L/min (4 US gal/min) @ 10 kPa |
| Maximum Pump Pressure | 0.2 Bar (2.9 psi) |
| Operating temp. | -40° to 120°C (-40° to 248°F) |
| Pump design | Recirculating centrifugal |
| Pump weight | 245 grams (0.54 lb) |
| Pump material | Nylon 66, 30% glass-filled |
| Burst pressure | 250 kPa (36 psi) minimum |
| Self Priming | No, none of our pumps are self priming |
| Fits hose sizes | 12.5mm to 19mm (½” to ¾”) using stepped adaptors |
Product Selection Guide | |||||||||||||||
|
Application |
Pump Model | Pump Kit | Pump Combo | Controller / Switch | |||||||||||
| Part # 12 V | Part # 24 V | Part# 12 V | Part # 24 V | Part # 12 V | Part # 24 V | ||||||||||
| Motorbike up to 500cc (Standard) | EBP15 | 9001 |
|
|
| 0444 or 0455 |
| ||||||||
|
Motorbike 500cc - 1000cc (Std) | EBP23 |
9050 |
|
|
|
0444 or 0455 |
| ||||||||
|
Motorbike 1000cc - 2000cc (Std) | EBP25 |
9005 |
|
|
|
0444 or 0455 |
| ||||||||
|
Vehicle Heater System (Standard) | EBP23 |
9050 |
|
|
|
0444 or 0455 |
| ||||||||
|
LPG (Butane) System (Standard) | EBP23 |
9050 |
|
|
|
0444 or 0455 |
| ||||||||
|
Intercooler (depending on capacity) | EBP23 | 9050 |
|
|
|
|
| ||||||||
| EBP25 | 9005 |
|
|
|
|
| |||||||||
| EBP40 | 9040 | 9041 |
|
| 0444 or 0455 | 0444 or 0455 | |||||||||
| EWP80 | 8005 |
| 8807 |
|
|
| |||||||||
|
Engines up to 2.0L (Standard) | EWP80 |
8005 |
|
8807 |
|
8000 |
8000 | ||||||||
|
Engines up to 2.0L - 3.5L (Standard) | EWP115 | 8025 or 8040 | 8026 or 8041 | 8830 or 8850 | 8831 or 8851 |
8000 |
8000 | ||||||||
|
Engines up to 3.5L - 5.0L (Standard) | EWP130 |
8080 |
8081 |
8890 |
8891 |
8000 |
8000 | ||||||||
|
Engines 5.0L or greater (Standard) | EWP150 |
8060 |
8061 |
8870 |
8871 |
8000 |
8000 | ||||||||
| Modified Engines Supercharged/Turbo | EWP150 |
8060 |
