CANchecked MFD15 Gen2 OLED Programmable CanBus Gauge Display Kit for Jeep Wrangler JK

Calculate Shipping

Australia wide rate - $20.00 (ETA: 3 days)

Want to keep an eye on what's happening with your A1 or S1 Audi? The CANchecked MFD15 plugs seamlessly into your Audi and displays ECU data on its OLED display. This kit includes an 8X specific housing which replaces an OEM air vent and looks factory. The vent remains functional with air able to move freely around the gauge.

The MFD15 Gen2 is CANcheck's newest and most versatile display and has revolutionised and rethought what is possible in the standard 52mm gauge form factor. The MFD15 is a CANbus compatible device which is able to read information from most 2008-onwards vehicles by simply plugging into your vehicles OBDII port. CANbus is currently how newer vehicles send and receive data. Think of it as a USB port on a computer; whatever is plugged into a USB port can be opened and accessed from your computer. If your CANbus ECU has sensors plugged in, then in most cases plugging a CANchecked display will read it* (see below for more information). Don't have a CANbus ECU in your car? No problem! The MFD15 can accept 6 additional inputs* (*license required) including Flex Fuel sensors directly to the gauge. No ECA module required.

The MFD15 however is more than just a gauge. It is also a data logging tool, a CAN sensor hub, a CAN control switch* (*license required, aftermarket ECUs only), a shift light and a warning light! Read below for a full list of features. Due to the small 52mm form factor the MFD15 can be mounted almost anywhere. To assist with installation however CANchecked off a range of direct-fit gauge bezels which allow bolt-in installation of the MFD15 display with a a look so clean it looks factory.

The MFD15 can be configured easily to display certain ECU values with a range of pre-made screen designs. This can be set up via PC or now with a WLAN connection from your phone directly to the MFD15. With an additional license data logging can be saved directly to your mobile device.

The CANchecked MFD15 is one of the best ways to monitor and enjoy your vehicle.

Features and Benefits

Key features of the MFD15 Gen2

WIRELESS INTERNET ACCESS: Connect to your smartphone for setup, customization and data logging* (*license required)
CANBUS: Access to our complete Can Bus database (TRI files) and our “Can Switching”* (*license required, aftermarket computers only)
COMPACT: 52mm installation diameter, 55mm bezel and only 12.5mm installation depth fits pretty much anywhere
ADDITIONAL SENSORS: Connect additional sensors to the 6 analog inputs usch as temperature, pressure, ethanol* and turbo speed* (license required)
PRESET ALARMS: Ready-made warnings can be easily activated and customised. For example, a big warning message when the exhaust gas temperature is over 900 degrees.
ONLINE LOGGING*: Log your data with your smartphone and save the log for later analysis (*license required)

Different views

The MFD15 can be customised to display data in many different ways:

Online DSS – oDSS

Brand new with our MFD15 Gen2 is access to the device via WLAN. This means you no longer necessarily need a laptop/PC for the settings on your display. Here you can set up your display completely, log values* (*license required), upload your own start image and also update the display.

Supported values

Many customers always ask: “Which values can I query from my control unit?” The answer: “ ALL ”. Our MFD15 is compatible with ISO 11898-2 and SAE J2284. The ECU manufacturers themselves determine which values are sent via the CAN bus interface. Documentation is important here - perhaps even in the form of a DBC file that can be imported via our DSS . You can also access our extensive list of already implemented control devices. These can be found in the download area . A total of up to 64 sensors can be queried if the manufacturer supports this.

Data that is available in broadcast as well as OBD2 queries via Can Bus (11bit/29bit) are implemented. Special protocols such as UDS are also available. If the desired control device is not listed, please contact us using the contact form

Included as standard:

All vehicles from around 2008 (OBD2 - 11bit/29bit)
Ecumaster Classic and Black
DTAfast
BMW E46 Can Bus
Haltech v2
Hondata
KMS van Kronenburg
LinkECU
MaxxECU
Motec M1
Emtron
Megasquirt 2 and 3
Syvecs
Trijekt
VW/AUDI PQ34/PQ35 etc.

All other TRI and TRX for your MFD15 Gen2 can be downloaded here .

Connection and Expansion

Each delivery includes:

Plug B (6-fold)
Plug C (12-fold)
20cm pre-crimped connection cable for power supply, CAN bus, analog inputs, 5V and sensor ground
Pins for crimping yourself
Two 1K resistors (for pull-up for NTC sensors)
