Expand the capability of your CANChecked MFD15 Gen 2 52mm CANbus display by purchasing a license to activate one of the following functions:

CAN Switching/Analogue Forwarding:

Allows the MFD15 to send CANbus commands and signals down the chain to your aftermarket ECU. CAN switching allows the MFD15 to send an "On/Off" type toggle which can be detected by certain aftermarket ECUs and can control ECU functions such as launch control, MAP switching, Anti-Lag, Fan activation etc.

Analogue Forwarding forwards the sensors (up to 6) connected to the display to certain aftermarket ECUs. These can be sensors, physical switches, position sensors or others.

MPP1 Frequency/Switched Input/Ethanol Flex Fuel Sensor Integration:

With the additional license for the frequency/switched MPP1 (multi-purpose pin 1) into you can add newer style sensors directly to the display. Some examples include an Ethanol Content Sensor and Turbo Speed Sensor. You need a pullup resistor (10K) between 5V and signal. Now you can view and log both the ethanol content and the fuel temperature.

Pair this with the CAN Switching/Analogue Forwarding license to send Ethanol content to your aftermarket ECU to flex fuel tuning!

You can choose to set this MPP1 to dim the display. Wire your +12V light switch to the pin, and the display dims as soon as +12V is feed in to the pin.

MPP2: Multi-Purpose Pin 2

MPP2 can be used to switch an output such as N75 clocking or water-methanol injection.

Online Logging:

Allows the MFD15 to log data via WLAN to your smart phone through the oDSS app. All sensors available from your ECU can be logged and graphed. Logs saved to the oDSS app can be downloaded to your phone or computer. Perfect for remote tuning!

MFD15 Complete License Package

This package includes all of the above licenses for a package price.

Fitment Table

Universal Fit
This product may require modification.
